AxisLock™ Rotary 4th/5th Axis 96/52mm Combo Zero Point Plate (Through Bore)
Quantity:
In Stock
✓ In Stock
✓ Ships in 1-3 Business Days
✓ Ships in 10-14 Days
✓ US-Based Support
-
Need Turnkey CNC Automation?
For Turnkeys and Custom Applications, we can help!
- Book a Turnkey Demo
Technical Specs & Downloads
3D CAD Viewer
Email address for CAD Model
Thanks for Submitting!
Your CAD Model will be sent to the email submitted within 1-2 minutes.
Loading 3D
CAD Viewer
Technical Specs
| Technical Specs | |
|---|---|
| Model | TO9652-200 |
| Dimensions | Ø7.87 × 1.18in || Ø200 × 30mm |
| Material | Hardened Stainless Steel |
| Weight | 14.3lbs || 6.5 kg |
| Mounting Holes | 6 × M10 |
| Locking Force | 5,000lbf || 22.2kN |
| Interface | Type 96 and Type 52 (96mm and 52mm pull stud pitch) |
Description
The AxisLock™ Rotary 4th/5th Axis 96/52mm Combo Zero Point Plate (Through Bore) is a precision-engineered zero point clamping solution designed for 4th and 5th axis CNC machining. Compatible with both 96mm and 52mm zero point systems, this combo plate features a through bore design for maximum flexibility in rotary automation setups.
Key Features
- Compatible with 96mm and 52mm zero point systems
- Through bore design for rotary 4th/5th axis applications
- Precision-machined for repeatable, high-accuracy clamping
- Built for demanding CNC automation environments
Perfect Pairings
Get the most out of your AxisLock™ setup by pairing it with these purpose-built Gimbel Automation systems:
- 4-Port AxisAir™ Universal 4th & 5th Axis Rotary Union Kit — Deliver pneumatic air through your rotary axis cleanly and reliably. The AxisAir™ is designed to work seamlessly with through-bore zero point plates like the AxisLock™, giving you full pneumatic control without compromising your rotary setup.
- AxisMount™ GripFlipGrip™ — 90° Trunnion Air Vise CNC Automation Module — Take your 4th/5th axis automation to the next level. The AxisMount™ GripFlipGrip™ mounts directly to your rotary axis and enables automated two-op part flipping, making it the ideal companion for high-throughput production runs on your AxisLock™ plate.
